SPECIFICATION
CPU | |
CPU Model | Realtek RTD1296 |
CPU Architecture | ARM64 64-bit |
CPU Frequency | Quad-Core 1.4GHz |
Memory | |
Memory | 1GB DDR4 |
Memory Expandable | Not expandable |
Flash Memory | 8GB eMMC |
Storage | |
Drive Bays | 2 |
Compatible Drive | 3.5" SATA HDD |
Maximum Drive Bays with Expansion Unit | 10 |
External Ports | |
Expansion | 2x USB 3.2 Gen 1 |
Network | 1x 2.5 Gigabit Ethernet (2.5G/1G/100M) |
Multimedia Output | N/A |
Others | |
System Fan | 1x 70mm |
Power Supply Unit / Adapter | 65W x1 |
Input Power Voltage | 100V to 240V AC |
Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC |
Warranty | 3 Years |
Operation | |
Power Consumption | 11.6W (Operation), 5.97W (Disk Hibernation) |
Noise Level | 18.6dB (HDD idle) |
Operation Temperature | 0°C |
Storage Temperature | -20°C |
Humidity | 5% to 95% RH |
Size and Weight | |
Size | 165(H) x 102(W) x 218(D) mm |
Weight | 1.14 kg / 2.5 lbs |
Supported OS | Windows 7, 8, 10, 11, Server 2008, Server 2012, Server 2016, Server 2019, Server 2022, macOS, UNIX, Linux, BSD |
Supported Languages | Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย |
Supported Browsers | Firefox, Chrome, Safari, Microsoft Edge |
Network | |
Network Protocols | CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog |
Connection and Transmission | TCP/IP (IPv4 & IPv6), Link Aggregation: 0, Jumbo Frame (MTU), VLAN, EZ Connect, Wireless Network, DDNS and EZ-Router, Supports Wake-on-LAN (WOL), Supports Wake-on-WAN (WOW) |
File Management & Sharing | |
File System | Internal Disk: EXT4, External Disk: FAT32, NTFS, EXT3, EXT4, HFS , exFAT |
File Explorer | Web-based File Management, ISO File Mounting, Share Links, Task Monitor, Browse Files on Local PC, Thumbnail Previews, Data Access via External Optical Drive, Supports video playback |
Network Recycle Bin | Share folder-based, Maintains original directory structure and file permission, On-click restore, Supports scheduled emptying, Filtering rules (File size, File extension), Deletion Settings (File size, File date) |
Storage Management | |
Supported RAID Levels | Single, JBOD, RAID 0, RAID 1 |
Supported RAID Migration Methods | Single to RAID 1, Volume |
RAID Levels Supporting Storage Expansion by Complete Drive Replacement | RAID 1 |
RAID Levels Supporting Storage Expansion by Drive Addition | - |
RAID Spare Drive Support | - |
iSCSI/IP-SAN | Maximum Targets: 256, Maximum LUNs: 265, Maximum Snapshot Versions of a Single LUN: 256, Target Masking, LUN Mapping, ISO File Mounting, Supports MPIO, Persistent (SCSI-3) Reservations |
Disk Management | Scheduled Bad Block Scans, Scheduled S.M.A.R.T Scans |
Access & Security | |
Access Control | Maximum Number of Users: 4096, Maximum Number of Groups: 512, Maximum Number of Shared Folders: 512, Maximum Number of Concurrent Connections: 512, Supports Windows Active Directory, Supports Windows Active Directory / LDAP |
ACL | Provides both Windows ACL and Linux ACL permission configuration methods, Can enable Windows ACL for specific shared folders, Comprehensive support for Windows’ 13 types of advanced permission settings, Can view Windows ACL permission settings from within ADM, Supports local users and groups, Exclusive permission reset function allows users to quickly restore default permissions |
System Administration | Log Type: System Log, Connection Log, File Access Log, Real-time Online User Monitor, Real-time System Monitor, User Quota, Virtual Drive (ISO Mounting, Maximum 16), UPS Support |
Security | AES 256-Bit Encryption, Firewall: Prevent Unauthorized Access, Alert Notifications: E-mail, SMS, Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH, Built-in Hardware Encryption Engine |
Network Defender | Auto black list, Trusted list, Black/White list, Supports IP/IP range/geolocation |
Backup | |
Backup Solutions | Rsync (Remote Sync) Backup, Cloud Backup, FTP Backup, External Backup, EZ Sync, SMB Backup |
Snapshots | iSCSI Snapshots, Support up to 256 Snapshots |
Others | |
ASUSTOR Highlight | System Migration, EZ Connect, Dr. ASUSTOR, 2-way Backup, Task Monitor |
Eco-Friendly Design | Auto-Standby for Both Internal and External Disks, Auto Fan Control, LED Night Mode, Power Schedule: On, Off, Restart |
Energy Control | Configurable Disk Hibernation Wait Time |
